High Performance Optical Modulators

PSI is a leader in the design and development of high performance optical modulators used in analog fiber optic system applications. PSI offers specialized optical modulator component products along with their electronic control circuits. PSI also offers design engineering services for those developing their own cutting edge modulator devices.

Custom Modulators and Design Services

Some of the world foremost designers of Lithium Niobate (LiNbO3), Gallium Arsenide (GaAs) and polymer optical modulators are members of the PSI technical team. Please contact PSI if custom optical modulator engineering design service is needed.

Devices

The PSI-2700-MOD=R1 consists of two Ti-indiffused lithium niobate Mach-Zehnder modulators (MZs) that share a common RF electrode.  Modulator 1 has the typical electrode configuration, with the RF electrode over one waveguide and one ground electrode over the other waveguide.  Modulator 2 has only the other ground providing modulation, so it will have a higher Vp.  When used in a link with external components the device produces a broadband linearized link.






DATA SHEETS

PSI-2700-MOD-R1 Linearizable Modulator
